| Color Car Rear Viewer Camera
|
|
|
|
| HMC-M410N
NTSC |
|
| HMC-M410P
PAL |
|
| |

|
|
| |
•Aluminum Housing Miniature-R/V Camera
•Weather proof high Sensitivity Color 1/4” CCD Camera
•Low-power Consumption & Wide viewing angle
•Excellent picture quality at low light sensitivity
•Supreme true color reproduction & clearest piture quality
•Aesthetic design & compact size for various user’s appllication
•Reverse polarity protection circuit built-in |
|
| COLOR CAMERA SPECIFICATIONS |
| Description |
HMC-M410N |
HMC-M410P |
| TV system |
NTSC |
PAL |
| Image sensor |
1/4inch CCD 270K pixels |
1/4inch CCD 320K pixels |
| Effective pixel |
510(H)X491(V) |
512(H)X581(V) |
| Scanning system |
525 Line 2:1 interlace |
625 Line 2:1 interlace |
| Scanning frequency |
15.734KHz(H), 59.94Hz(V) |
15.625KHz (H), 50Hz(V) |
| Sync. System |
Internal |
| Horizontal resolution |
330TV lines (Center) |
| Min. Illumination |
0.5lx / F=1.2(AGC ON) |
| S/N ratio |
45dB (AGC OFF) |
| Gamma |
γ= 0.45 |
| White balance |
ATW |
| AGC |
ON |
| IRIS |
Electrical Auto IRIS |
| Shutter speed |
1/60~1/100,000 sec. |
1/50~1/100,000 sec. |
| Video Output |
1.0Vp-p, 75ohm |
| BLC |
ON |
| Power Consumption |
DC8V~15V, Max. 120mA(DC 12V) |
| OperatingTemp |
-10°C~60°C |
| Dimensions(mm) |
ø32 X 80.4mm |
| Housing materia |
Aluminum |
|
|
 |
